| 650V&750V SiC Devices | |||||||
| Image | Part Number | Datasheet | Voltage | Id | Package | Configuration | SPICE |
 |
SD300HB65C2 | 650V | 300A | 34mm | SiC Diode Module | SPICE | |
 |
QXTS025N075 | 750V | 25mΩ@75A | TSPAK-7L | SiC MOS | SPICE | |
|
1200V SiC Devices |
|||||||
| Image | Part Number | Datasheet | Voltage | Id | Package | Configuration | SPICE |
 |
HPSC600FS12 | 1200V | 3.2mΩ@600A | HPD | 3-Phase | SPICE | |
|
HPSC800FS12 | 1200V | 2.5mΩ@800A | HPD | 3-Phase | SPICE | |
 |
EDSC300X12 | 1200V | 4mΩ@300A | ED3 | Half Bridge | SPICE | |
|
EDSC300X12KM | 1200V | 3.5mΩ@300A | ED3 | Half Bridge, With SBD | SPICE | |
|
EDSC450X12 | 1200V | 3.5mΩ@450A | ED3 | Half Bridge | SPICE | |
|
EDSC450X12K | 1200V | 3.5mΩ@450A | ED3 | Half Bridge, With SBD | SPICE | |
|
EDSC600X12 | 1200V | 1.6mΩ@600A | ED3 | Half Bridge | SPICE | |
|
EDSC600X12K | 1200V | 1.6mΩ@600A | ED3 | Half Bridge, With SBD | SPICE | |
|
EDSC900X12K | 1200V | 1.4mΩ@900A | ED3 | Half Bridge, With SBD | SPICE | |
 |
SC200HB12C1 | 1200V | 8mΩ@200A | 62mm | Half Bridge | SPICE | |
|
SC200HB12C1K | 1200V | 8mΩ@200A | 62mm | Half Bridge, With SBD | SPICE | |
|
SC250HB12C1DTP | 1200V | 6.8mΩ@250A | 62mm | Half Bridge | SPICE | |
|
SC300HB12C1 | 1200V | 3.7mΩ@300A | 62mm | Half Bridge | SPICE | |
 |
SC300HB12C1K | 1200V | 3.7mΩ@300A | 62mm | Half Bridge, With SBD | SPICE | |
|
SC300SL12C1K | 1200V | 3.7mΩ@300A | 62mm | Chopper HS | SPICE | |
|
SC300SL12C1KR | 1200V | 3.7mΩ@300A | 62mm | Chopper LS | SPICE | |
|
SC450HB12C1 | 1200V | 2.6mΩ@450A | 62mm | Half Bridge | SPICE | |
|
SC450HB12C1K | 1200V | 2.6mΩ@450A | 62mm | Half Bridge, With SBD | SPICE | |
|
SC600HB12C1K | 1200V | 1.6mΩ@600A | 62mm | Half Bridge, With SBD | SPICE | |
|
SC100HB12C2 | 1200V | 15mΩ@100A | 34mm | Half Bridge, AMB | SPICE | |
|
SC100HB12C2K | 1200V | 15mΩ@100A | 34mm | Half Bridge, AMB, With SBD | SPICE | |
|
SC100HB12C2L | 1200V | 15mΩ@100A | 34mm | Half Bridge, DBC | SPICE | |
|
SC100HB12C2KL | 1200V | 15mΩ@100A | 34mm | Half Bridge, DBC, With SBD | SPICE | |
|
SC180HB12C2 | 1200V | 7.5mΩ@180A | 34mm | Half Bridge, AMB | SPICE | |
|
SC180HB12C2K | 1200V | 7.5mΩ@180A | 34mm | Half Bridge, AMB, With SBD | SPICE | |
|
SC180HB12C2L | 1200V | 7.5mΩ@180A | 34mm | Half Bridge, DBC | SPICE | |
|
SC180HB12C2KL | 1200V | 7.5mΩ@180A | 34mm | Half Bridge, AMB, With SBD | SPICE | |
|
SC300HB12C2 | 1200V | 3.9mΩ@300A | 34mm | Half Bridge, AMB | SPICE | |
|
SC200SL12C2K | 1200V | 8.5mΩ@300A | 34mm | Chopper HS | ||
 |
SC75HB12B2 | 1200V | 75A | Easy2B | Half Bridge | SPICE | |
|
|
SC150FP12B2 | 1200V | 7mΩ@150A | Easy2B | Four Pack H-Bridge | SPICE | |
|
|
SC160HB12B2 | 1200V | 160A | Easy2B | Half Bridge | SPICE | |
|
|
SC320HB12B2 | 1200V | 3.5mΩ@320A | Easy2B | Half Bridge | PLECS | |
|
|
SC160TN12B2 | 1200V | 160A | Easy2B | NPC2 | SPICE | |
|
|
SC080FS12B2 | 1200V | 33.6mΩ@80A | Easy2B | 3-Phase | SPICE | |
|
|
SC080FS14B2 | 1400V | 33.6mΩ@80A | Easy2B | 3-Phase | SPICE | |
|
|
SC160FS12B2 | 1200V | 19.3mΩ@160A | Easy2B | 3-Phase | SPICE | |
|
|
SC160FS14B2 | 1400V | 19.3mΩ@160A | Easy2B | 3-Phase | SPICE | |
 |
SC160N12S1 | 1200V | 14mΩ@160A | SOT-227 | SiC MOS | SPICE | |
|
|
SC160N12S1K | 1200V | 14mΩ@160A | With SBD | SiC MOS, With SBD | SPICE | |
|
SC75N12S1 | 1200V | 30mΩ@75A | SOT-227 | SiC MOS | SPICE | |
|
|
SC75N12S1K | 1200V | 30mΩ@75A | With SBD | SiC MOS, With SBD | SPICE | |
|
SD080N12S1 | 1200V | 80A | SOT-227 | SiC Diode | SPICE | |
|
SD100N12S1 | 1200V | 100A | SOT-227 | SiC Diode | SPICE | |
 |
QXDP080N120 | 1200V | 30mΩ@80A | QDPAK | SiC MOS | SPICE | |
|
QXDP160N120 | 1200V | 15mΩ@160A | QDPAK | SiC MOS | SPICE | |
|
QXDP250N120 | 1200V | 7mΩ@250A | QDPAK | SiC MOS | SPICE | |
|
QXDP400N120 | 1200V | 4mΩ@400A | QDPAK | SiC MOS | SPICE | |
|
|
QX4L080N120 | 1200V | 80mΩ@35A | TO247-4L | SiC MOS | SPICE | |
 |
QX3L080N120 | 1200V | 80mΩ@35A | TO247-3L | SiC MOS | SPICE | |
 |
QX4L030N120 | 1200V | 30mΩ@75A | TO247-4L | SiC MOS | SPICE | |
 |
QX4L030N120B | 1200V | 30mΩ@75A | TO247PLUS-4L | SiC MOS | SPICE | |
|
QX3L030N120 | 1200V | 30mΩ@75A | TO247-3L | SiC MOS | SPICE | |
|
QX3L025N120 | 1200V | 25mΩ@75A | TO247-3L | SiC MOS | SPICE | |
 |
QX7L030N120 | 1200V | 30mΩ@75A | TO263-7L | SiC MOS | SPICE | |
 |
QXTL030N120 | 1200V | 30mΩ@75A | TOLL | SiC MOS | SPICE | |
|
QX4L014N120 | 1200V | 14mΩ@160A | TO247-4L | SiC MOS | SPICE | |
|
QX4L011N120 | 1200V | 11mΩ@180A | TO247-4L | SiC MOS | SPICE | |
|
QX3L014N120 | 1200V | 14mΩ@160A | TO247-3L | SiC MOS | SPICE | |
|
QX4L025N140 | 1200V | 25mΩ@75A | TO247-4L | SiC MOS | SPICE | |
 |
RT120030SDH-A | 1200V | 17mΩ | CIPS | - | SPICE | |
 |
SC080HB12MP9 | 1200V | 30mΩ | MSOP9 | Half Bridge | SPICE | |
 |
QXTS014N120 | 1200V | 14mΩ@160A | TSPAK-7L | SiC MOS | SPICE | |
|
QXTS025N120 | 1200V | 25mΩ@75A | TSPAK-7L | SiC MOS | SPICE | |
 |
QXC30R12 | 1200V | 75A | Bare Die | 30mΩ | SPICE | |
|
QXC14R12 | 1200V | 160A | Bare Die | 14mΩ | SPICE | |
 |
62mm&34mm SiC 碳化硅模块驱动板 |
1200V | - | Drive Broad | - | - | |
 |
ED3 SiC 碳化硅模块驱动板 |
1200V | - | Drive Broad | - | - | |
| 1700V SiC Devices | |||||||
| Image | Part Number | Datasheet | Voltage | Id | Package | Configuration | SPICE |
 |
HPSC600FS17 | 1700V | 600A | HPD | 3-Phase | SPICE | |
|
HPSC800FS17 | 1700V | 800A | HPD | 3-Phase | SPICE | |
|
EDSC300X17K | 1700V | 3.5mΩ@300A | ED3 | Half Bridge, With SBD | SPICE | |
|
EDSC450X17K | 1700V | 2.5mΩ@450A | ED3 | Half Bridge, With SBD | SPICE | |
|
EDSC600X17 | 1700V | 600A | ED3 | Half Bridge | SPICE | |
|
EDSC900X17K | 1700V | 1.3mΩ@900A | ED3 | Half Bridge, With SBD | SPICE | |
|
EDSC900X17KM | 1700V | 1.3mΩ@900A | ED3 | Half Bridge, With SBD | SPICE | |
|
SC200HB17C1K | 1700V | 200A | 62mm | Half Bridge, With SBD | SPICE | |
|
SC300HB17C1K | 1700V | 3.7mΩ@300A | 62mm | Half Bridge, With SBD | SPICE | |
|
SC450HB17C1 | 1700V | 450A | 62mm | Half Bridge | SPICE | |
|
SC450HB17C1K | 1700V | 2.6mΩ@450A | 62mm | Half Bridge, With SBD | SPICE | |
|
SC600HB17C1K | 1700V | 1.8mΩ@600A | 62mm | Half Bridge, With SBD | SPICE | |
|
SC75N17S1 | 1700V | 75A | SOT-227 | SiC MOS | SPICE | |
|
SC75N17S1K | 1700V | 75A | SOT-227 | SiC MOS, With SBD | SPICE | |
|
SD50N17S1 | 1700V | 50A | SOT-227 | SiC Diode | SPICE | |
|
SD100N17S1 | 1700V | 100A | SOT-227 | SiC Diode | SPICE | |
|
SC160N17S1 | 1700V | 160A | SOT-227 | SiC MOS | SPICE | |
|
SC160N17S1K | 1700V | 160A | SOT-227 | SiC MOS, With SBD | SPICE | |
|
QXDP080N170 | 1700V | 30mΩ@80A | QDPAK | SiC MOS | SPICE | |
|
QXDP160N170 | 1700V | 15mΩ@160A | QDPAK | SiC MOS | SPICE | |
|
QXDP250N170 | 1700V | 7mΩ@250A | QDPAK | SiC MOS | SPICE | |
|
QXDP400N170 | 1700V | 4mΩ@400A | QDPAK | SiC MOS | SPICE | |
 |
QX3L014N170 | 1700V | 14mΩ@160A | TO247-3L | SiC MOS | SPICE | |
|
QX3L030N170 | 1700V | 30mΩ@75A | TO247-3L | SiC MOS | SPICE | |
|
QX4L014N170 | 1700V | 14mΩ@160A | TO247-4L | SiC MOS | SPICE | |
|
QX4L030N170 | 1700V | 30mΩ@75A | TO247-4L | SiC MOS | SPICE | |
|
QXC14R17 | 1700V | 160A | Bare Die | 14mΩ | SPICE | |
| 2200V and Above SiC Devices | |||||||
| Image | Part Number | Datasheet | Voltage | Id | Package | Configuration | SPICE |
|
QXC28R22 | 2200V | 100A | Bare Die | 28mΩ | SPICE | |
 |
SC100DF20B3 | 2000V | 17mΩ@100A | Easy3B | Boost | SPICE | |
|
EDSC250X22 | 2200V | 250A | ED3 | Half Bridge | SPICE | |
 |
SC100HB22C1 | 2200V | 13mΩ@100A | 62mm | Half Bridge | SPICE | |
|
SC200HB22C1 | 2200V | 7mΩ@200A | 62mm | Half Bridge | SPICE | |
|
SC300HB22C1 | 2200V | 300A | 62mm | Half Bridge | SPICE | |
|
SC400HB22C1 | 2200V | 400A | 62mm | Half Bridge | SPICE | |
|
SC240HB23B2 | 2300V | 5mΩ@240A | Easy2B | Half Bridge | PLECS | |
|
QX4L030N220A | 2200V | 30mΩ@100A | TO247-4L | 30mΩ | SPICE | |
|
QX4L030N220B | 2200V | 30mΩ@100A | TO247PLUS-4L | 30mΩ | ||
 |
QX4L030N220C | 2200V | 30mΩ@100A | TO247HCC-4L | 30mΩ | SPICE | |
| 3300V and Above SiC Devices | |||||||
| Image | Part Number | Datasheet | Voltage | Id | Package | Configuration | SPICE |
 |
SC100HB33C1 | 3300V | 100A | 62mm | Half Bridge | SPICE | |
|
SC200HB33C1 | 3300V | 200A | 62mm | Half Bridge | SPICE | |
|
SC300HB33C1 | 3300V | 300A | 62mm | Half Bridge | SPICE | |
 |
SC600HB33M1 | 3300V | 600A | XHP | Half Bridge | SPICE | |
|
SC900HB33M1 | 3300V | 900A | XHP | Half Bridge | SPICE | |
|
SC1200HB33M1 | 3300V | 1200A | XHP | Half Bridge | SPICE | |
 |
SC100HB33B2 | 3300V | 100A | Easy2B | H-Bridge | SPICE | |
|
SC200HB33B2 | 3300V | 200A | Easy2B | H-Bridge | SPICE | |
 |
QX4L025N330B | 3300V | 100A | TO247PLUS-4L | SiC MOS | SPICE | |
|
QX4L025N330C | 3300V | 100A | TO247HCC-4L | SiC MOS | SPICE | |
|
QXC25R33 | 3300V | 100A | Bare Die | - | SPICE | |
